MOES Star Ring Series 65W Fast Charging PD3.0 Wall Electrical Outlet Charger GaN Socket

TK-SR-EU-2C1A-65
Main Features:

1.Three Ports Support Fast Charging: Each port supports fast charging technology. Under different fast charging port combinations, the output power is automatically adjusted to ensure that the optimal charging efficiency can be achieved under different combinations, whether it is charging a single device or multiple devices at the same time.

2.Variety of Protocols Supported: Support Protocol for C port：PD3.0, PPS, FCP, SCP, AFC, QC2.0, QC3.0, BC1.2 . Support Protocol for A port：QC2.0, QC3.0, AFC, FCP, SCP, BC1.2

3.Over-temperature Protection through Built-in NTC: When the built-in NTC detects that the socket temperature is too high, the socket's output power will be reduced to ensure the safety of the socket.

4.Excellent Safety Performance: Multiple safety features, including overvoltage, overcurrent, overload, overtemperature, and undervoltage protection, ensure safe usage.

product details

Product Features

Super professional remote monitoring on APP and PC: convenient daily usage, smart large-scale aftersales without time and location limitation.
Built-in MPPT solar charge controller
Wide PV input voltage range (60V to 450V), minimum connect 2pcs PV panel, save installation cost.
Max 8 pcs in parallel, extend loading capacity to 49.6KW
Smart tuya communication bar(Easy management for users)
Built-in anti-dust kit for harsh environment, avoid short circuit.
High efficiency (max 97.5%), no-load loss less than 30W.
Run without battery
Combining solar system, AC utility, and battery power source to supply continuous power(10MS transfer time)
Dual back up load port(EPS port& smart port)
Support power the load and charge battery at the same time by 1.7 rates of Input Utility power
Overload, short circuit and Deep discharge protection of battery
Intelligent fan speed regulation, reduce noise and power consumption.
5 year warranty.

Applications of Inverters

1. Solar Power Generation: Converts the direct current (DC) produced by solar panels into alternating current (AC) for grid connection or self-use.
2. Electric Vehicles: Converts the DC from the battery into AC to drive the electric motor.
3. Household Appliances: Provides backup power during outages by converting DC from batteries into AC for home use.
4. Industrial Equipment: Supplies AC power to equipment that requires it.

Product Display

MOES WiFi Smart Hybrid Solar Inverter01MOES WiFi Smart Hybrid Solar Inverter02MOES WiFi Smart Hybrid Solar Inverter03MOES WiFi Smart Hybrid Solar Inverter04MOES WiFi Smart Hybrid Solar Inverter05MOES WiFi Smart Hybrid Solar Inverter06MOES WiFi Smart Hybrid Solar Inverter07
详情图 (1)
详情图 (2)
详情图 (3)
010203

TK-SR-EU-2C1A-65TECHNICAL SPECIFICATIONS

Model: TK-SR-EU-2C1A-65

Input: 100-240Vac，50/60Hz. 1.5A Max

USB-C1/C2 output: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3.25A MAX

USB-A output: 5V/4.5A, 9V/3A, 12V/3A, 20V/2.25A

C1+C2=45W+18W, C1+USB A=45W+18W，C2+USB A=15W, C1+C2+USB A = 45W+15W

C Support Protocol：PD3.0,PPS,FCP,SCP,AFC,QC2.0,QC3.0,BC1.2

A Support Protocol：QC2.0,QC3.0,AFC,FCP,SCP,BC1.2
